Triumph Street Twin User Manual

Maintenance and Adjustment
148
Direction Indicator Lights
The motorcycle is fitted with either LED
or bulb direction indicator lights.
LED Direction Indicator Lights
The LED direction indicator light units
are sealed, maintenance free LED units.
The direction indicator light assembly
must be replaced in the event of the
failure of the direction indicator.
Street Scrambler and Street Twin
Direction Indicator Bulb
Replacement
1
3
2
1. Lens
2. Bulb
3. Indicator lens screw
The lens on each indicator light is held
in place by an indicator lens screw
located in the body of the light unit.
To replace the direction indicator light
bulb:
• Release the indicator lens screw and
remove the lens to gain access to
the bulb for replacement.
• Carefully remove the bulb and
replace it with a new bulb.
• Installation is the reverse of the
removal procedure.
Bonneville T100, Bonneville T120,
Bonneville T120 Ace and
Thruxton RS Direction Indicator
Bulb Replacement
3
21
1. Bulb
2. Locating tangs
3. Lens
To replace the direction indicator light
bulb:
• Carefully twist the lens anti-
clockwise and remove from the
indicator to gain access to the bulb.
• Gently press the bulb inwards and
twist anticlockwise. Replace with a
new bulb.
• Installation for the bulb is the
reverse of the removal procedure.
Caution
When installing the lens, make sure
that the locating tangs are correctly
aligned to the indicator body.
• To install the indicator lens, align
the locating tangs with the indicator
body and twist anticlockwise to
secure.

Triumph Street Twin Specifications

General

Engine Type	Liquid-cooled, 8 valve, SOHC, 270° crank angle parallel twin
Displacement	900 cc
Bore x Stroke	84.6 x 80 mm
Compression Ratio	11.0:1
Max Torque	80 Nm @ 3, 800 rpm
Fuel System	Multipoint sequential electronic fuel injection
Final Drive	Chain
Clutch	Wet, multi-plate assist clutch
Gearbox	5-speed
Frame	Tubular steel, twin cradle
Front Tire	100/90-18
Rear Tire	150/70 R17
Dry Weight	198 kg
Wet Weight	216 kg
Fuel Consumption	4.1 l/100 km
CO2 Emissions	93 g/km
Max Power	65 PS (64 bhp) @ 7, 500 rpm
Exhaust	Brushed 2 into 2 exhaust system with twin brushed silencers
Front Suspension	41mm forks
Rear Suspension	Twin shocks with adjustable preload
Front Brakes	Single 310mm disc, Nissin 2-piston floating caliper
Rear Brakes	Single 255mm disc, Nissin 2-piston floating caliper
Front Wheel	Cast aluminium alloy, 18 x 2.75 in
Rear Wheel	Cast aluminium alloy, 17 x 4.25 in
Seat Height	765 mm
Fuel Tank Capacity	12L
Width (Handlebars)	780 mm
Wheelbase	1450 mm
Rake	25.1 °
Trail	102.4 mm
