Triumph Street Twin User Manual

Maintenance and Adjustment
149
License Plate Light
Bonneville T100 (all models),
Bonneville T120 (all models),
Speed Twin and Thruxton RS
The license plate light unit is a sealed,
maintenance free LED unit. The license
plate light unit must be replaced in the
event of the failure of the license plate
light.
Street Scrambler and Street Twin
321 4
1. Fixing
2. Lens unit
3. Bulb
4. License plate bracket
To change the license plate light bulb:
• Disconnect the battery, negative
black lead first.
• Release the fixing from the lens
unit.
• Remove the lens unit from the
license plate bracket.
• Detach the bulb retainer from the
lens unit.
1
2
1. Bulb
2. Bulb retainer
• Carefully remove the bulb from the
bulb retainer. Fit a new bulb into the
bulb retainer.
• Refit the bulb retainer into the lens
unit.
• Refit the lens unit to the license
plate bracket.
• Tighten the fixing to 1 Nm.
• Reconnect the battery, positive (red)
lead first and tighten the battery
terminals to 4.5 Nm.
• Apply a light coat of grease to the
terminals to prevent corrosion.
• Cover the positive terminal with the
protective cap.

Triumph Street Twin Specifications

General

Engine Type	Liquid-cooled, 8 valve, SOHC, 270° crank angle parallel twin
Displacement	900 cc
Bore x Stroke	84.6 x 80 mm
Compression Ratio	11.0:1
Max Torque	80 Nm @ 3, 800 rpm
Fuel System	Multipoint sequential electronic fuel injection
Final Drive	Chain
Clutch	Wet, multi-plate assist clutch
Gearbox	5-speed
Frame	Tubular steel, twin cradle
Front Tire	100/90-18
Rear Tire	150/70 R17
Dry Weight	198 kg
Wet Weight	216 kg
Fuel Consumption	4.1 l/100 km
CO2 Emissions	93 g/km
Max Power	65 PS (64 bhp) @ 7, 500 rpm
Exhaust	Brushed 2 into 2 exhaust system with twin brushed silencers
Front Suspension	41mm forks
Rear Suspension	Twin shocks with adjustable preload
Front Brakes	Single 310mm disc, Nissin 2-piston floating caliper
Rear Brakes	Single 255mm disc, Nissin 2-piston floating caliper
Front Wheel	Cast aluminium alloy, 18 x 2.75 in
Rear Wheel	Cast aluminium alloy, 17 x 4.25 in
Seat Height	765 mm
Fuel Tank Capacity	12L
Width (Handlebars)	780 mm
Wheelbase	1450 mm
Rake	25.1 °
Trail	102.4 mm
