Triumph Street Twin User Manual

General Information
46
If OFF ROAD mode is selected, it is
shown in the main display.
10
20
110
120
120
0
0
20
40
0
180
200
1
1. OFF ROAD mode display (Street Scrambler
only)
When in OFF ROAD mode, a long press
on the MODE button changes the riding
mode to ROAD mode.
Selecting a Riding Mode – with the
Motorcycle Stationary
Press and release the MODE button on
either the left or right hand handlebar
switch housing (model specific) until the
required riding mode is flashing in the
display.
The selected riding mode is
automatically activated one second
after the MODE button is pressed, if the
following conditions are met:
With the Engine Off
• The ignition is switched ON.
• The engine stop switch is in the
RUN position.
With the Engine Running
• The transmission is in neutral or the
clutch is pulled in.
Selecting a Riding Mode – when
Riding the Motorcycle
Warning
The selection of riding modes whilst
the motorcycle is in motion requires
the rider to allow the motorcycle to
coast (motorcycle moving, engine
running, throttle closed, clutch lever
pulled in and no brakes applied) for a
brief period of time.
Riding mode selection whilst the
motorcycle is in motion should only be
attempted:
- At low speed
- In traffic free areas
- On straight and level roads or
surfaces
- In good road and weather conditions
- Where it is safe to allow the
motorcycle to briefly coast.
Riding mode selection whilst the
motorcycle is in motion MUST NOT be
attempted:
- At high speeds
- Whilst riding in traffic
- During cornering or on winding roads
or surfaces
- On steeply inclined roads or surfaces
- In poor road/weather conditions
- Where it is unsafe to allow the
motorcycle to coast.
Failure to observe this important
warning will lead to loss of motorcycle
control and an accident.

Triumph Street Twin Specifications

General

Engine Type	Liquid-cooled, 8 valve, SOHC, 270° crank angle parallel twin
Displacement	900 cc
Bore x Stroke	84.6 x 80 mm
Compression Ratio	11.0:1
Max Torque	80 Nm @ 3, 800 rpm
Fuel System	Multipoint sequential electronic fuel injection
Final Drive	Chain
Clutch	Wet, multi-plate assist clutch
Gearbox	5-speed
Frame	Tubular steel, twin cradle
Front Tire	100/90-18
Rear Tire	150/70 R17
Dry Weight	198 kg
Wet Weight	216 kg
Fuel Consumption	4.1 l/100 km
CO2 Emissions	93 g/km
Max Power	65 PS (64 bhp) @ 7, 500 rpm
Exhaust	Brushed 2 into 2 exhaust system with twin brushed silencers
Front Suspension	41mm forks
Rear Suspension	Twin shocks with adjustable preload
Front Brakes	Single 310mm disc, Nissin 2-piston floating caliper
Rear Brakes	Single 255mm disc, Nissin 2-piston floating caliper
Front Wheel	Cast aluminium alloy, 18 x 2.75 in
Rear Wheel	Cast aluminium alloy, 17 x 4.25 in
Seat Height	765 mm
Fuel Tank Capacity	12L
Width (Handlebars)	780 mm
Wheelbase	1450 mm
Rake	25.1 °
Trail	102.4 mm
