Triumph Street Twin User Manual

General Information
58
High Beam Light
When the high beam button is
pressed the high beam will be
switched on. Each press of
the button will swap between
dip and high beam.
Note
If daytime running lights are fitted to
the motorcycle, the high beam button
has additional functionality.
If the DRL switch is in the daytime
running lights position, then press and
hold the high beam button to turn the
high beam on. It will remain on as long
as the button is held in and will turn off
as soon as the button is released.
Note
A lighting on/off switch is not fitted to
this model. The rear light and licence
plate light all function automatically
when the ignition is on.
The headlight will function when the
ignition is on. The headlight will go off
while pressing the starter button until
the engine starts.
Heated Grips (if fitted)
The heated grips work when the
ignition is switched on. However, it is
recommended that they are only used
when the engine is running to avoid
draining the battery.
There are two heat levels; low or high.
1
1. Heated grips button
The heated grips button is located on
the left hand grip.
Press the heated grip button to show
the current status of the heated grips
in the display screen. This is shown for
three seconds.
Press the heated grip button whilst the
status is showing to select one of the
three different heat levels; OFF, Lo (low)
or HI (high).
For maximum benefit in cold conditions,
use the heated grips on the HI level
initially and when the grips have
warmed up, change to Lo.
To switch off the heated grips, press
and release the button until OFF is
shown in the display screen. The heated
grips are also switched off when the
ignition is switched off.

Triumph Street Twin Specifications

General

Engine Type	Liquid-cooled, 8 valve, SOHC, 270° crank angle parallel twin
Displacement	900 cc
Bore x Stroke	84.6 x 80 mm
Compression Ratio	11.0:1
Max Torque	80 Nm @ 3, 800 rpm
Fuel System	Multipoint sequential electronic fuel injection
Final Drive	Chain
Clutch	Wet, multi-plate assist clutch
Gearbox	5-speed
Frame	Tubular steel, twin cradle
Front Tire	100/90-18
Rear Tire	150/70 R17
Dry Weight	198 kg
Wet Weight	216 kg
Fuel Consumption	4.1 l/100 km
CO2 Emissions	93 g/km
Max Power	65 PS (64 bhp) @ 7, 500 rpm
Exhaust	Brushed 2 into 2 exhaust system with twin brushed silencers
Front Suspension	41mm forks
Rear Suspension	Twin shocks with adjustable preload
Front Brakes	Single 310mm disc, Nissin 2-piston floating caliper
Rear Brakes	Single 255mm disc, Nissin 2-piston floating caliper
Front Wheel	Cast aluminium alloy, 18 x 2.75 in
Rear Wheel	Cast aluminium alloy, 17 x 4.25 in
Seat Height	765 mm
Fuel Tank Capacity	12L
Width (Handlebars)	780 mm
Wheelbase	1450 mm
Rake	25.1 °
Trail	102.4 mm
