Triumph Street Twin User Manual

General Information
40
Fuel Gauge
Street Scrambler and Street Twin
Only
10
20
30
40
90
100
110
120
120
0
0
20
40
60
80
120
140
160
180
200
21
1. Low fuel indicator light
2. Fuel gauge
All Other Models
1
2
1. Fuel gauge
2. Low fuel indicator light
The fuel gauge indicates the amount
of fuel in the tank. With the ignition
switched on, the number of bars shown
in the display indicates the level of fuel.
When the fuel tank is full all eight bars
are displayed and when empty, no bars
are displayed. Other gauge markings
indicate intermediate fuel levels
between full and empty.
When there are approximately 3 litres of
fuel remaining in the tank, the low fuel
warning light will illuminate.
Note
After refuelling, the fuel gauge and
range to empty information will
be updated only while riding the
motorcycle. Depending on the riding
style, updating could take up to five
minutes.

Triumph Street Twin Specifications

General

Engine Type	Liquid-cooled, 8 valve, SOHC, 270° crank angle parallel twin
Displacement	900 cc
Bore x Stroke	84.6 x 80 mm
Compression Ratio	11.0:1
Max Torque	80 Nm @ 3, 800 rpm
Fuel System	Multipoint sequential electronic fuel injection
Final Drive	Chain
Clutch	Wet, multi-plate assist clutch
Gearbox	5-speed
Frame	Tubular steel, twin cradle
Front Tire	100/90-18
Rear Tire	150/70 R17
Dry Weight	198 kg
Wet Weight	216 kg
Fuel Consumption	4.1 l/100 km
CO2 Emissions	93 g/km
Max Power	65 PS (64 bhp) @ 7, 500 rpm
Exhaust	Brushed 2 into 2 exhaust system with twin brushed silencers
Front Suspension	41mm forks
Rear Suspension	Twin shocks with adjustable preload
Front Brakes	Single 310mm disc, Nissin 2-piston floating caliper
Rear Brakes	Single 255mm disc, Nissin 2-piston floating caliper
Front Wheel	Cast aluminium alloy, 18 x 2.75 in
Rear Wheel	Cast aluminium alloy, 17 x 4.25 in
Seat Height	765 mm
Fuel Tank Capacity	12L
Width (Handlebars)	780 mm
Wheelbase	1450 mm
Rake	25.1 °
Trail	102.4 mm
