Triumph Street Twin User Manual

General Information
37
Traction Control (TC) Disabled
Warning Light
The TC disabled warning light
should not illuminate unless
traction control is switched
off or there is a malfunction.
If the warning light becomes illuminated
at any other time while riding, it
indicates that the traction control
system has a malfunction that requires
investigation.
Direction Indicators
When the direction indicator
switch is turned to the left or
right, the direction indicator
warning light will flash on and
off at the same speed as the direction
indicators.
High Beam
When the ignition is switched
ON and the high beam is
selected, the high beam
warning light will illuminate.
Daytime Running Lights (DRL)
(if fitted)
When the ignition is switched
ON and the daytime running
lights switch is set to Daytime
Running Lights, the daytime
running lights warning light will
illuminate.
The daytime running lights and low
beam headlights are operated manually
using a switch on the left hand switch
housing, see page 37.
Warning
Do not ride for longer than necessary
in poor ambient light conditions with
the Daytime Running Lights (DRL) in
use.
Riding with the Daytime Running
Lights when dark, in tunnels or where
poor ambient light is apparent may
reduce the riders vision or dazzle
other road users.
Dazzling other road users or reduced
vision in low ambient light levels may
result in loss of motorcycle control and
an accident.
Note
During daylight hours the Daytime
Running Lights (DRL) improve the
motorcycles visibility to other road
users.
Low beam headlights must be used
in any other conditions unless the
road conditions allow for high beam
headlights to be used.
Neutral
The neutral warning light
indicates when the
transmission is in neutral (no
gear selected). The warning
light will illuminate when the
transmission is in neutral with the
ignition switch in the ON position.

Triumph Street Twin Specifications

General

Engine Type	Liquid-cooled, 8 valve, SOHC, 270° crank angle parallel twin
Displacement	900 cc
Bore x Stroke	84.6 x 80 mm
Compression Ratio	11.0:1
Max Torque	80 Nm @ 3, 800 rpm
Fuel System	Multipoint sequential electronic fuel injection
Final Drive	Chain
Clutch	Wet, multi-plate assist clutch
Gearbox	5-speed
Frame	Tubular steel, twin cradle
Front Tire	100/90-18
Rear Tire	150/70 R17
Dry Weight	198 kg
Wet Weight	216 kg
Fuel Consumption	4.1 l/100 km
CO2 Emissions	93 g/km
Max Power	65 PS (64 bhp) @ 7, 500 rpm
Exhaust	Brushed 2 into 2 exhaust system with twin brushed silencers
Front Suspension	41mm forks
Rear Suspension	Twin shocks with adjustable preload
Front Brakes	Single 310mm disc, Nissin 2-piston floating caliper
Rear Brakes	Single 255mm disc, Nissin 2-piston floating caliper
Front Wheel	Cast aluminium alloy, 18 x 2.75 in
Rear Wheel	Cast aluminium alloy, 17 x 4.25 in
Seat Height	765 mm
Fuel Tank Capacity	12L
Width (Handlebars)	780 mm
Wheelbase	1450 mm
Rake	25.1 °
Trail	102.4 mm
