Triumph Street Twin User Manual

General Information
43
To switch between trip meters, press
and release the SCROLL button, located
on the left hand handlebar switch
housing, until the required trip meter is
shown.
1
cixb_1
1. SCROLL button
Note
Street Scrambler Only
The trip meters are not accessible when
in OFF ROAD mode. The trip meter data
continues to be collected when riding in
OFF ROAD mode. The updated trip meter
data is shown in the trip meters after
switching the OFF ROAD mode off.
Trip Meter Reset
To reset either of the trip meters:
• Select the trip meter to be zeroed.
• Press and hold the SCROLL button
for one second. After more than one
second, the trip meter on display will
reset to zero.
Clock
To access the clock, press and release
the SCROLL button, located on the left
hand handlebar switch housing, until
the clock is shown.
10
20
30
100
110
120
120
0
0
20
40
60
0
160
180
200
1
1. Clock
Clock Adjustment
Warning
Do not attempt to adjust the clock
with the motorcycle in motion as this
may lead to loss of motorcycle control
and an accident.
To reset the clock:
• Select the clock display.
• Press and hold the SCROLL button
for one second, the clock’s hour
display will start to flash. Release
the SCROLL button.

Triumph Street Twin Specifications

General

Engine Type	Liquid-cooled, 8 valve, SOHC, 270° crank angle parallel twin
Displacement	900 cc
Bore x Stroke	84.6 x 80 mm
Compression Ratio	11.0:1
Max Torque	80 Nm @ 3, 800 rpm
Fuel System	Multipoint sequential electronic fuel injection
Final Drive	Chain
Clutch	Wet, multi-plate assist clutch
Gearbox	5-speed
Frame	Tubular steel, twin cradle
Front Tire	100/90-18
Rear Tire	150/70 R17
Dry Weight	198 kg
Wet Weight	216 kg
Fuel Consumption	4.1 l/100 km
CO2 Emissions	93 g/km
Max Power	65 PS (64 bhp) @ 7, 500 rpm
Exhaust	Brushed 2 into 2 exhaust system with twin brushed silencers
Front Suspension	41mm forks
Rear Suspension	Twin shocks with adjustable preload
Front Brakes	Single 310mm disc, Nissin 2-piston floating caliper
Rear Brakes	Single 255mm disc, Nissin 2-piston floating caliper
Front Wheel	Cast aluminium alloy, 18 x 2.75 in
Rear Wheel	Cast aluminium alloy, 17 x 4.25 in
Seat Height	765 mm
Fuel Tank Capacity	12L
Width (Handlebars)	780 mm
Wheelbase	1450 mm
Rake	25.1 °
Trail	102.4 mm
