Triumph Street Twin User Manual

Parts Identification
16
Parts Identification
Bonneville T100 (all models) and Bonneville T120 (all models)
(Bonneville T120 shown)
1
2
3
4
5
6
7
8
91 0111213
14
15
16
17
1. Front direction indicator
2. Headlight
3. Clutch lever
4. Battery (under seat)
5. Owner’s Handbook (under seat) or
supplied separately
6. Brake/rear light
7. Rear direction indicator
8. Rear brake disc
9. Rear brake caliper
10. Coolant expansion tank
11. Coolant expansion tank cap
12. Side stand
13. Gear change pedal
14. Horn
15. Radiator
16. Front brake caliper
17. Front brake disc

Triumph Street Twin Specifications

General

Engine Type	Liquid-cooled, 8 valve, SOHC, 270° crank angle parallel twin
Displacement	900 cc
Bore x Stroke	84.6 x 80 mm
Compression Ratio	11.0:1
Max Torque	80 Nm @ 3, 800 rpm
Fuel System	Multipoint sequential electronic fuel injection
Final Drive	Chain
Clutch	Wet, multi-plate assist clutch
Gearbox	5-speed
Frame	Tubular steel, twin cradle
Front Tire	100/90-18
Rear Tire	150/70 R17
Dry Weight	198 kg
Wet Weight	216 kg
Fuel Consumption	4.1 l/100 km
CO2 Emissions	93 g/km
Max Power	65 PS (64 bhp) @ 7, 500 rpm
Exhaust	Brushed 2 into 2 exhaust system with twin brushed silencers
Front Suspension	41mm forks
Rear Suspension	Twin shocks with adjustable preload
Front Brakes	Single 310mm disc, Nissin 2-piston floating caliper
Rear Brakes	Single 255mm disc, Nissin 2-piston floating caliper
Front Wheel	Cast aluminium alloy, 18 x 2.75 in
Rear Wheel	Cast aluminium alloy, 17 x 4.25 in
Seat Height	765 mm
Fuel Tank Capacity	12L
Width (Handlebars)	780 mm
Wheelbase	1450 mm
Rake	25.1 °
Trail	102.4 mm
