Triumph Street Twin User Manual

General Information
35
High Coolant Temperature Warning
Light
With the engine running,
if the engine coolant temp-
erature becomes dangerously
high, the high coolant
temperature warning light will illuminate.
Caution
Stop the engine immediately if the
high coolant temperature warning
light illuminates. Do not restart
the engine until the fault has been
rectified.
Severe engine damage will result from
running the engine when the high
coolant temperature warning light is
illuminated.
Engine Immobiliser/Alarm Indicator
Light
This Triumph motorcycle is
fitted with an engine
immobiliser which is activated
when the ignition switch is
turned to the OFF position.
Without Alarm Fitted
When the ignition switch is turned
to the OFF position, the engine
immobiliser/alarm light will flash on and
off for 24 hours to show that the engine
immobiliser is on. When the ignition
switch is turned to the ON position the
engine immobiliser and the indicator
light will be off.
If the indicator light remains on it
indicates that the engine immobiliser
has a malfunction that requires
investigation. Contact an authorised
Triumph dealer as soon as possible to
have the fault checked and rectified.
With Alarm Fitted
The engine immobiliser/alarm light will
only illuminate when the conditions
described in the genuine Triumph
accessory alarm instructions are met.
Anti-lock Braking System (ABS)
Warning Light
Warning
If the ABS is not functioning, the brake
system will continue to function as a
non-ABS equipped brake system.
Do not continue to ride for longer than
is necessary with the warning light
illuminated.
Contact an authorised Triumph dealer
as soon as possible to have the fault
checked and rectified. In this situation
braking too hard will cause the wheels
to lock resulting in loss of motorcycle
control and an accident.

Triumph Street Twin Specifications

General

Engine Type	Liquid-cooled, 8 valve, SOHC, 270° crank angle parallel twin
Displacement	900 cc
Bore x Stroke	84.6 x 80 mm
Compression Ratio	11.0:1
Max Torque	80 Nm @ 3, 800 rpm
Fuel System	Multipoint sequential electronic fuel injection
Final Drive	Chain
Clutch	Wet, multi-plate assist clutch
Gearbox	5-speed
Frame	Tubular steel, twin cradle
Front Tire	100/90-18
Rear Tire	150/70 R17
Dry Weight	198 kg
Wet Weight	216 kg
Fuel Consumption	4.1 l/100 km
CO2 Emissions	93 g/km
Max Power	65 PS (64 bhp) @ 7, 500 rpm
Exhaust	Brushed 2 into 2 exhaust system with twin brushed silencers
Front Suspension	41mm forks
Rear Suspension	Twin shocks with adjustable preload
Front Brakes	Single 310mm disc, Nissin 2-piston floating caliper
Rear Brakes	Single 255mm disc, Nissin 2-piston floating caliper
Front Wheel	Cast aluminium alloy, 18 x 2.75 in
Rear Wheel	Cast aluminium alloy, 17 x 4.25 in
Seat Height	765 mm
Fuel Tank Capacity	12L
Width (Handlebars)	780 mm
Wheelbase	1450 mm
Rake	25.1 °
Trail	102.4 mm
