Triumph Street Twin User Manual

General Information
38
Low Fuel Indicator Light
The low fuel indicator light will
illuminate when there are
approximately 3 litres of fuel
remaining in the tank.
Tyre Pressure Warning Light
Warning
Stop the motorcycle if the tyre
pressure warning light illuminates.
Do not ride the motorcycle until the
tyres have been checked and the tyre
pressures are at their recommended
pressure when cold.
Note
Tyre Pressure Monitoring System
(TPMS) is an accessory option only
available on models fitted with cast alloy
wheels.
The tyre pressure warning
light works in conjunction
with the Tyre Pressure
Monitoring System (TPMS)
(see page 51).
The warning light will only illuminate
when the front or rear tyre pressure is
below the recommended pressure. It will
not illuminate if the tyre is over inflated.
When the warning light is illuminated,
the TPMS symbol indicating which is
the deflated tyre and its pressure will
automatically be shown in the display
screen.
10
20
30
40
90
100
110
120
120
0
0
20
40
60
80
100
120
140
160
180
200
1
2
3
4
1. Tyre pressure warning light
2. TPMS symbol
3. Tyre pressure
4. Front and rear tyre indicators
The tyre pressure at which the warning
light illuminates is temperature
compensated to 20°C but the numeric
pressure display associated with it
is not. Even if the numeric display
seems at or close to the standard tyre
pressure when the warning light is on,
a low tyre pressure is indicated and a
puncture is the most likely cause.
General Warning Symbol
The general warning symbol will
flash if an ABS or engine
management fault has occurred
and the ABS and/or MIL warning lights
are illuminated. Contact an authorised
Triumph dealer as soon as possible to
have the fault checked and rectified.

Triumph Street Twin Specifications

General

Engine Type	Liquid-cooled, 8 valve, SOHC, 270° crank angle parallel twin
Displacement	900 cc
Bore x Stroke	84.6 x 80 mm
Compression Ratio	11.0:1
Max Torque	80 Nm @ 3, 800 rpm
Fuel System	Multipoint sequential electronic fuel injection
Final Drive	Chain
Clutch	Wet, multi-plate assist clutch
Gearbox	5-speed
Frame	Tubular steel, twin cradle
Front Tire	100/90-18
Rear Tire	150/70 R17
Dry Weight	198 kg
Wet Weight	216 kg
Fuel Consumption	4.1 l/100 km
CO2 Emissions	93 g/km
Max Power	65 PS (64 bhp) @ 7, 500 rpm
Exhaust	Brushed 2 into 2 exhaust system with twin brushed silencers
Front Suspension	41mm forks
Rear Suspension	Twin shocks with adjustable preload
Front Brakes	Single 310mm disc, Nissin 2-piston floating caliper
Rear Brakes	Single 255mm disc, Nissin 2-piston floating caliper
Front Wheel	Cast aluminium alloy, 18 x 2.75 in
Rear Wheel	Cast aluminium alloy, 17 x 4.25 in
Seat Height	765 mm
Fuel Tank Capacity	12L
Width (Handlebars)	780 mm
Wheelbase	1450 mm
Rake	25.1 °
Trail	102.4 mm
