6 TEAMWORK, STANDBY AND ROTATIONFORCOOLINGUNITS
NOTE: Your Liebert® DSE™ Packaged Solution does not offer humidification or dehumidification functions. Please
disregard those settings/fields when mentioned in this guide or displayed on the iCOM controller.
iCOM unit to unit communication via private network and additional hardware allows the following operating features for the
cooling units. (See Unit to Unit Networking on page57)
• Teamwork
• Standby (Rotation)
• Cascade
6.1 Continuous Control with Virtual Master
The Virtual Master function maintains smooth control if group communication is compromised. In these operating
configurations, a lead (master) unit is in charge of component staging in teamwork mode, unit staging, and stand-by
rotation. If the lead unit gets disconnected, iCOM automatically assigns a virtual master, which assumes the responsibilities
of the lead unit until communication is restored.
6.2 Teamwork Modes
When iCOM controlled thermal management units are connected to a network in a group or team, use teamwork to
optimize performance and efficiency depending on the mode chose and its application.
In a panel with Status content, the Teamwork mode icon indicates the mode selected, Figure 6.1 on the next page.
Touching the icon displays the Teamwork dialog from which you can access the teamwork control settings.
6.2.1 To Set Up Team Work
1. Touch the Teamwork-mode icon, then touch Edit on the teamwork dialog.
– or –
Touch , then > BMS & Teamwork Setup > Teamwork / Standby > TeamworkMode.
2. Select the mode from the Teamwork Mode drop down in the TEAMWORK MODE CONTROL panel. The
TEAMWORK/STANDBY panel opens.
3. Touch Save. Teamwork mode is set.
• Touch Cancel to discard changes.
6 Teamwork, Standby and RotationforCoolingUnits
63
