Page 54 of 81
6 Loc3-10Tx Transmitter
3. Press “f” pushbutton to move the box down and the “+” and “-” pushbuttons to select the second frequency.
Multi Freq Setup
32.8kHz
83.1kHz
200kHz
4. Repeat step three to select the third frequency if needed.
5. Press “i” pushbutton to return to main display. On the main display, “Multi” will appear indicating the multi-frequency mode
is active.
MULTI
3 3 2mA
6. The frequencies selected for multi-frequency mode will be saved until changes are made even when the multi-frequency
mode is deactivated.
6.5 Remote the Operation of transmitter
The Loc3-10Tx can be remotely operated from the receiver. This is an optional feature and requires the transmitter radio link
option to be installed in both the vLoc3-Pro and Loc3-10Tx. This feature is only available on the Loc3-10Tx and is a factory t
option so must be requested at the time of ordering. The range of the radio link depends on having a clear “line of sight” between
Rx and Tx but is typically around 300m (984ft).
Linking a transmitter to a receiver:
Switch on the transmitter, press the information button repeatedly to scroll through the options until the “RECEIVER LINK
DISABLED” option is displayed.
