Technical Data
Type designation D13–700 D13–800
Aftermarket designation D13C3-A MP D13C4-A MP
Crankshaft power @ 2300 r/min.
(1)
515 kW (700 hk) 588 kW (800 hk)
Max torque. 2570 Nm (1895 lbf.ft)/1200–1900
rpm
2934 Nm (2164 lbf.ft)/1300–1900
rpm
No. of cylinders 6 6
Bore 131 mm
(5.16”)
131 mm
(5.16”)
Stroke 158 mm
(6.22”)
158 mm
(6.22”)
Displacement
12,78 dm
3
(779.7 in
3
)
12,78 dm
3
(779.7 in
3
)
Engine, dry weight 1560 kg
(3439 lbs)
1450 kg
(3197 lbs)
Compression ratio 16.5:1 16.7:1
Low idle, r/min.
(2)
600 (±10) 600 (±10)
1) According to ISO 8665
2) At delivery, the idle speed is adjusted to 600 r/min. If needed, the speed can be adjusted within the range550–800 r/min.
47708638 09-2016 © AB VOLVO PENTA 137
Lubrication System
Oil capacity including oil filters, approx.:
no engine inclination 45 liters (11.9 US gal)
Oil pressure, hot engine:
Oil pressure during operation 300–550 kPa (43.5–79.8 psi)
Oil pressure during neutral 175 kPa (25.4 psi)
Oil quality
(1)
Sulfur content in fuel, by weight
up to 0,5% 0,5–1,0%
more than 1,0%
(2)
Oil change interval, reached first in operation:
VDS-3 500 hours or 12 months 250 hours or 12 months 125 hours or 12 months
1)) Lowest recommended oil grade. Engine oil with higher oil grade is always possible to u
2)) If sulphur content is more than 1.0 per cent by weight, use oil with TBN over
NOTICE!
Mineral based oil, either fully or semi-synthetic, can be used on condition that it complies with the quality
requirements above.
TBN = Total Base Number
VDS = Volvo Drain Specification
