7" Display
The 7” display is an optional supplement to the Volvo
Penta control system. Via the display it is possible to
view and control all installed functions in the system.
IMPORTANT:
Prolonged exposure to strong sunlight may damage
the screen and cause functional faults.
Make a habit of protecting the screen by using the
protective cover when the boat is not in use.
Navigate the system using the knob and the three
buttons.
Turn the knob to navigate in the submenus and
to return to the main menu.
Return to the previous menu.
Confirm a selection. The button can also be
used to access submenus and the Settings page.
Controls the instrument backlight. If contrast
changes are not confirmed, the display contrast
reverts automatically shortly after the button is
released.
The status field (2) on the right side of the screen
displays the current view, active functions and repaired
faults.
My View
Boat, engine and transmission data is displayed in My
View as analog or digital instruments.
In the menu Customize, it is possible to select which
instruments to display and how they are presented.
Information for to up to three engines can be displayed
on the screen. Color coding is used to separate the
information for the different engines.
Instruments and Controls
30 47708638 09-2016 © AB VOLVO PENTA
