13 Technical data
100_0202_td_0004.fm
102
13 Technical data
13.1 DPU 130Le
Unit
Designation Unit DPU 130Le
DPU 130Le US
Item no. 5000610143 5000610424
Length x width x height mm 1270 x 1202 x 996
Vertical clearance mm 996
Operating weight kg 1170
Travel speed *
* Depending on the soil properties.
m/min 31
Compaction performance* m²/h 2232
Maximum allowable slanting position ° 25
Electrical load rating **** kW 17.9
Nominal speed rpm 3000
Maximum operating time with
maximum permissible slanting
position **
** Exceeding the maximum permissible operating time leads to engine damage.
min 30
Permissible ambient temperature for
operation
°C -10 — +50
Measured sound power level dB(A) 108
Guaranteed sound power level dB(A) 109
Sound pressure level L
pA
at the
operator's position***
***Measured from a distance of 5 m from the unit.
**** Corresponds to the net installed power in accordance with directive 2000/14/EC.
dB(A) 87
