DPU 130Le 10 Troubleshooting
Operator's manual
98
10.6 Eliminating malfunctions
10.6.1 Jumpstart with a donor battery
If the machine's battery is discharged and the engine can no longer be started,
the machine may be jumpstarted with a donor battery.
Note: Use only insulated booster cables with a cross section of at least
16 mm².
Removing positive terminal cover
1. Lift up the battery cover until the battery's positive terminal is visible.
2. Remove positive terminal cover.
WARNING
Danger of explosion due to detonating gas.
Injury may result from spraying acid.
f Wear safety glasses and acid-proof protective gloves.
f The donor battery and the machine's battery must have the same
voltage (12 V).
f Avoid short circuit due to voltage reversal (positive to positive, negative to
negative).
f Follow the booster cable connection sequence.
Item Designation Item Designation
1 Grounding 3 Positive terminal
2 Donor battery 4 Battery cover
