9 Maintenance
81
100_0202_mt_0004.fm
9.2.5 Checking/cleaning/replacing air cleaner
Performing preparations
1. Place the machine upright on a flat surface.
2. Open rear protective hood.
3. Deactivate the machine.
Checking air cleaner
X Check whether the air cleaner clamps are fitted securely and whether the air
cleaner is undamaged.
X Check whether the dust discharge valve is dirty.
If necessary, compress the dust discharge valve in order to remove the dirt.
Item Designation
1 Air cleaner
2 Dust discharge valve
