Xerox 6204 User Guide

2 Product Overview
34 Xerox 6204 Wide Format Solution
Product Overview
2
Loading Media
Loading Roll Media
Set up the roll media on Roll 1 or Roll 2.
Important • When setting the roll media, take care not to pinch your fingers in the machine.
• When changing the media types, size, or weight, make sure to change the media settings
before starting copying. For information about the setting procedure, refer to "Media
Settings" (P.39).
Note • Roll 2 is an optional addition to the machine.
1 Open the front doors.
2 Pull out the drawer for Roll 1 or Roll 2.
3 Remove the shaft of the roll media from the
machine.
4 Pinch the lever at the end of the shaft, and
remove the shaft from the core of the roll media.
Note • Pinching the lever releases the lock of the roll
media, and you can remove the shaft.

Xerox 6204 Specifications

General

Brand	Xerox
Model	6204
Category	All in One Printer
Language	English
