Xerox 6204 User Guide

Media Types and Loading
Xerox 6204 Wide Format Solution 37
Product Overview
2
Cutting Roll Media
The following describes how to cut the lead edge of the roll media loaded on Roll 1 or
Roll 2.
1 Open the front doors.
2 Pull out the drawer for Roll 1 or Roll 2.
3 Press the cutter button to cut the lead edge of
the media.
The lead edge of the media is cut.
Important • Do not open the cutter cover for Roll 1 or
Roll 2.
Note • Pressing the cutter button one time cuts the
paper at a length of 8.3 inches (210 mm).
When the cutter button is held down, the media
is continuously loaded until the cutter button is
released. The media is cut when the cutter
button is released.
4 Remove the piece of paper that was cut.
5 Gently slide the Roll 1 or Roll 2 drawer into the
machine until it stops and latches.

Xerox 6204 Specifications

General

Brand	Xerox
Model	6204
Category	All in One Printer
Language	English
