Trouble
sh
ooting
238
Xerox
®
WorkCentre
®
7220/7220i/7225/7225i Co
lor Multifunc
tion Printer
User G
uid
e
5.
C
lose t
he fuse
r by pus
hing
in the ha
ndle unt
il it st
ops
.
CAUTION:
To a
void damage to
the printer, verif
y that the fuser is close
d before proceed
ing
.
6.
Close door A, then close tray 5.
Clearing
Jams
at D
oor D
1.
Open tray 5.
2.
Open doo
r D.
237
239
