Identifying the components
The HCS is comprised of the following components:
1. Control Panel: Provides manual control of the various HCS functions
2. Top Tray: Holds a maximum of 500 sheets
Note
Labels must be delivered to the Top Tray.
3. Bypass: Used only when a second stacking/finishing device is installed. This path
transports media through the HCS to another connected finishing device.
4. Stacker Tray/Cart: Collated sets (up to a total of 5000 sheets) are transported to
the Stacker Tray, which is located on a moveable Stacker Cart.
