ColorQube 8570/8870 Service Manual
Fault Messages and Codes
Xerox Internal Use Only - Revised, 3rd Revision
94,514 Drum Image Race Timing The imaging data was not filled and/or received
soon enough from PS to start imaging the current
Y-Axis rev.
94,516 Drum Image Abort
94,518 Drum Image Timing The imaging sequence started too late.
94,558 Dm Timing Error
Table 1 Fault Codes
Fault Code Name Description
