Xerox COLORQUBE 8570 Service Manual

October 2012
6-48
ColorQube 8570/8870 Service Manual
OF4, OF5
Revised, 3rd Revision - Xerox Internal Use Only
General Troubleshooting
OF4 Tray 1 - Squeaking
Tray 1 may make a squeaking noise when it picks the last sheet from a stack of paper. In some
cases, depending on the type of paper being used, the squeaking sound may be noticed dur
-
ing the picking of any sheet of the stack.
Troubleshooting Reference
Applicable Part (Chapter 5 - Parts List)
• Separator Pad Kit, PL 3.1 Item 9
Procedure
Check that the squeaking is not too loud. Is the squeaking sound loud?
YN
Troubleshooting complete.
Replace the Separator Pad Kit (REP 3.9).
OF5 Tray 1 - Buzzing, Grinding
The printer makes a buzzing, grinding sound during the print process when Tray 1 Roller is out
of position.
Procedure
Check for a buzzing, grinding sound during the print process. Is there a buzzing, grinding
sound?
YN
Troubleshooting complete.
Open and close Tray 1. This will reset the Pick Roller position and should eliminate the noise.

Xerox COLORQUBE 8570 Specifications

General

Print Technology	Solid Ink
Monthly Duty Cycle	Up to 85, 000 pages
First Page Out Time (Color)	As fast as 5 seconds
First Page Out Time (B&W)	As fast as 5 seconds
Memory (Maximum)	1 GB
Output Capacity	350 sheets
Supported Operating Systems	Windows, Mac OS, Linux
Print Speed	Up to 40 ppm color / 40 ppm black
Connectivity	USB 2.0, Ethernet
Print Languages	PCL 6, PostScript 3, PDF
