Xinje DS5F Series User Manual

147
n.0□□□
Third notch off
n.0□□□
Anytime
At once
n.1□□□
Third notch on
P2-70
n.□□□0
Fourth notch off
n.□□□0
Anytime
At once
n.□□□1
Fourth notch on
n.□□0□
Fifth notch off
n.□□0□
Anytime
At once
n.□□1□
Fifth notch on
Parameter
Meaning
Default
setting
Unit
Range
Change
Effective
P2-71
First notch frequency
5000
Hz
50～5000
Anytime
At once
P2-72
First notch attenuation
70
0.1dB
50～1000
Anytime
At once
P2-73
First notch bandwidth
0
Hz
0～1000
Anytime
At once
P2-74
Second notch frequency
5000
Hz
50～5000
Anytime
At once
P2-75
Second notch attenuation
70
0.1dB
50～1000
Anytime
At once
P2-76
Second notch bandwidth
0
Hz
0～1000
Anytime
At once
P2-77
Third notch frequency
5000
Hz
50～5000
Anytime
At once
P2-78
Third notch attenuation
70
0.1dB
50～1000
Anytime
At once
P2-79
Third notch bandwidth
0
Hz
0～1000
Anytime
At once
P2-80
Fourth notch frequency
5000
Hz
50～5000
Anytime
At once
P2-81
Fourth notch attenuation
70
0.1dB
50～1000
Anytime
At once
P2-82
Fourth notch bandwidth
0
Hz
0～1000
Anytime
At once
P2-83
Fifth notch frequency
5000
Hz
50～5000
Anytime
At once
P2-84
Fifth notch attenuation
70
0.1dB
50～1000
Anytime
At once
P2-85
Fifth notch bandwidth
0
Hz
0～1000
Anytime
At once
Note:
1. In the adaptive mode, if the vibration is detected, the second notch filter will be automatically
configured.
2. In the auto-tuning mode, the second and first notches will be automatically configured if the
vibration is detected (the second notches will be preferentially opened when there is only one vibration
point).
3. Whether in self-adaptive or auto-tuning mode, if the mechanical characteristic analysis is sued, it
belongs to manual setting of notches, please configure the third to fifth notches.
