Xinje DS5F Series User Manual

174
P2-69.0
Notch filter 1 switch
-
0
0~1
√
1|2|3|4|5|6|7|
8|9|10
6.4.6
P2-69.1
Notch filter 2 switch
-
0
0~1
√
1|2|3|4|5|6|7|
8|9|10
6.4.6
P2-69.3
Notch filter 3 switch
-
0
0~1
√
1|2|3|4|5|6|7|
8|9|10
-
P2-70.0
Notch filter 4 switch
-
0
0~1
√
1|2|3|4|5|6|7|
8|9|10
-
P2-70.1
Notch filter 5 switch
-
0
0~1
√
1|2|3|4|5|6|7|
8|9|10
-
P2-71
First notch frequency
Hz
5000
50~5000
√
1|2|3|4|5|6|7|
8|9|10
6.7.7
P2-72
First notch attenuation
0.1dB
70
50~1000
√
1|2|3|4|5|6|7|
8|9|10
6.7.7
P2-73
First notch band width
Hz
0
0~1000
√
1|2|3|4|5|6|7|
8|9|10
6.7.7
P2-74
Second notch frequency
Hz
5000
50~5000
√
1|2|3|4|5|6|7|
8|9|10
6.7.7
P2-75
Second notch attenuation
0.1dB
70
50~1000
√
1|2|3|4|5|6|7|
8|9|10
6.7.7
P2-76
Second notch band width
Hz
0
0~1000
√
1|2|3|4|5|6|7|
8|9|10
6.7.7
P2-77
Third notch frequency
Hz
5000
50~5000
√
1|2|3|4|5|6|7|
8|9|10
6.7.7
P2-78
Third notch attenuation
0.1dB
70
50~1000
√
1|2|3|4|5|6|7|
8|9|10
6.7.7
P2-79
Third notch band width
Hz
0
0~1000
√
1|2|3|4|5|6|7|
8|9|10
6.7.7
P2-80
Fourth notch frequency
Hz
5000
50~5000
√
1|2|3|4|5|6|7|
8|9|10
6.7.7
P2-81
Fourth notch attenuation
0.1dB
70
50~1000
√
1|2|3|4|5|6|7|
8|9|10
6.7.7
P2-82
Fourth notch band width
Hz
0
0~1000
√
1|2|3|4|5|6|7|
8|9|10
6.7.7
P2-83
Fifth notch frequency
Hz
5000
50~5000
√
1|2|3|4|5|6|7|
8|9|10
6.7.7
P2-84
Fifth notch attenuation
0.1dB
70
50~1000
√
1|2|3|4|5|6|7|
8|9|10
6.7.7
P2-85
Fifth notch band width
Hz
0
0~1000
√
1|2|3|4|5|6|7|
8|9|10
6.7.7
P3-XX:
Parameter
Function
Unit
Default value
Range
Effective
Suitable
mode
Reference
chapter
P3-00
V-REF Function
Allocation
0-V-REF as Speed
Instruction Input
1-V-REF will be used
as input reference
value of external speed
limit. The actual speed
limit depends on the
speed limit of external
analog quantity.
-
0
0~2
○
1|2|4
5.5
