Page 115FTDX9000D OPERATION MANUAL
The memory system of the FT DX 9000D allows storage and recall of up to 99 memories, each storing frequency, mode, and
a wide variety of status information detailed previously. Memories may be grouped into as many as six Memory Groups,
and additionally you get nine pairs of band-limit (PMS) memories along with five QMB (Quick Memory Bank) memories.
MEMORY STORAGE
1. Set the Main (VFO-A) band up with all frequency,
mode, and status the way you want to have it stored.
2. Press the
AM button (# ) momentarily (the cur-
rent channel number will start blinking); the contents
of the current memory channel will be shown on the
Sub (VFO-B) display field.
3. Press the
MCH/GRP key (# ) momentarily.
When you press the MCH/GRP switch, the Red
LED imbedded within the switch should light up, in-
dicating that you are ready to choose a channel into
which to store the data.
Advice
H If the Red LED imbedded in the MCH/GRP switch does
not light up, check to be sure that the orange lamp to the right
of the CLAR/VFO-B knob is not illuminated. It it is, press
the A/B switch to make it go out, then press the MCH/
GRP] key again.
4. Rotate the CLAR/VFO-B knob to select the memory
channel onto which you wish to store the data. If you
have selected a channel on which data is already stored,
that frequency will appear on the Sub (VFO-B) band's
frequency display field.
5. Press and hold in the AM key for two seconds to
store the frequency and other data into the selected
memory channel. A double beep will confirm that you
have held the AM key in long enough.
MEMORY CHANNEL RECALL
1 Press the V/M switch (# ), if necessary, to enter
the Memory mode. A memory channel number will
appear in the multi-panel window.
2. Press the MCH/GRP key (# ) momentarily.
The Red LED inside the switch will light up, indicat-
ing that you are ready to recall a memory channel.
Advice
H If the Red LED imbedded in the MCH/GRP switch does
not light up, check to be sure that the orange lamp to the right
of the CLAR/VFO-B knob is not illuminated. It it is, press
the A/B switch to make it go out, then press the MCH/
GRP key again.
3. After pressing the MCH/GRP key, you may rotate
the CLAR/VFO-B knob to select the desired
memory channel.
MEMORY OPERATION
Advice
To work within a particular Memory Group, press and hold
in the MCH/GRP key for two seconds. The imbedded
LED will glow Orange; now press the MCH/GRP key
momentarily, and the LED will change to Red; you mauy
now choose the channel within the selected Memory Group.
CLAR/VFO-B knob
A M key
MCH/GRP switch
V/M key
CLAR/VFO-B knob
V/M key
MCH/GRP switch
