4 - 1
ENG
EC400000
ENGINE
SEAT, FUEL TANK AND SIDE COVERS
5PA40010
Extent of removal:
1
Seat removal
2
Fuel tank removal
3
Side covers removal
4
Number plate removal
Extent of removal Order Part name Q’ty Remarks
Preparation for removal
SEAT, FUEL TANK AND SIDE
COVERS REMOVAL
Turn the fuel cock to “OFF”.
Disconnect the fuel hose.
1Seat 1
2 Air scoop 1
3 Bolt (fuel tank) 2
4 Fuel tank 1
5 Left side cover 1
6 Right side cover 1
7 Number plate 1
1 3
4
2
3
SEAT, FUEL TANK AND SIDE COVERS
