Yamaha RX-V3900 Service Manual

40
RX-V3900/DSP-AX3900
RX-V3900/
DSP-AX3900
DSP1 DA70Y DSP2 DA70YLC89057
Analog
Digital
A/D
DIR
DECODE
DSP
POST
PROCESSING
DSP
PCM1804
SL/SR
DIR L/R
C
PL/PR
SBL/SBR or PL/PR
SWL/SWR
L/R
L/R
64Mbit
SDRAM
AD L/R
DSP THROUGH
(ANALOG)
(Shaded items not used in this mode)
A2. BYPASS
ANALOG BYPASS
A2.BYPASS
ANALOGBYPASS
DSP BYPASS
DSPBYPASS
INPUT: DVD ANALOG
SPEAKER OUT: 1kHz, SUBWOOFER OUTPUT: 50Hz
INPUT: DVD ANALOG
SPEAKER OUT: 1kHz, SUBWOOFER OUTPUT: 50Hz
Input level Volume
SPEAKER OUT
SUBWOOFER
OUTPUT
FRONT CENTER SURROUND
SURROUND
BACK
PRESENCE
(SP1)
ZONE2
(SP2)
Both ch, -20 dBm +6.5 dB +13.0 dBm -∞ -∞ -∞ -∞ -∞ -∞
Input level Volume
SPEAKER OUT
SUBWOOFER
OUTPUT
FRONT CENTER SURROUND
SURROUND
BACK
PRESENCE
(SP1)
ZONE2
(SP2)
Both ch, -20 dBm +6.5 dB -∞ -∞ -∞ -∞ -∞ -∞ -∞
A2.BYPASS
DSPBYPASS
A2.BYPASS
ANALOG
