Yamaha RX-V3900 Service Manual

44
RX-V3900/DSP-AX3900
RX-V3900/
DSP-AX3900
A5. MULTI CH INPUT
It is possible to select the 6ch/8ch input and 6-ohm/8-
ohm by using the sub-menu.
6CH INPUT_6-ohm
A5.MULTICHINPUT
サブメニューにより、6ch/8ch 入力および 6 オーム
/8 オームが選択可能です。
6CHINPUT6 オーム
8CH INPUT_6-ohm
8CHINPUT6 オーム
INPUT: MULTI CH INPUT
SPEAKER OUT: 1kHz, SUBWOOFER OUTPUT: 50Hz
INPUT: MULTI CH INPUT
SPEAKER OUT: 1kHz, SUBWOOFER OUTPUT: 50Hz
6CH INPUT_8-ohm
6CHINPUT8 オーム
8CH INPUT_8-ohm
8CHINPUT8 オーム
INPUT: MULTI CH INPUT
SPEAKER OUT: 1kHz, SUBWOOFER OUTPUT: 50Hz
INPUT: MULTI CH INPUT
SPEAKER OUT: 1kHz, SUBWOOFER OUTPUT: 50Hz
Input level Volume
SPEAKER OUT
SUBWOOFER
OUTPUT
FRONT CENTER SURROUND
SURROUND
BACK
PRESENCE
(SP1)
ZONE2
(SP2)
Both ch, -20 dBm +6.5 dB +13.0 dBm +13.0 dBm +13.0 dBm -∞ -∞ -∞ -16.0 dBm
Input level Volume
SPEAKER OUT
SUBWOOFER
OUTPUT
FRONT
(DVD)
CENTER SURROUND
SURROUND
BACK
PRESENCE
(SP1)
ZONE2
(SP2)
Both ch, -20 dBm +6.5 dB -∞ +13.0 dBm +13.0 dBm +13.0 dBm -∞ -∞ -16.0 dBm
Input level Volume
SPEAKER OUT
SUBWOOFER
OUTPUT
FRONT CENTER SURROUND
SURROUND
BACK
PRESENCE
(SP1)
ZONE2
(SP2)
Both ch, -20 dBm +6.5 dB +13.0 dBm +13.0 dBm +13.0 dBm -∞ -∞ -∞ -16.0 dBm
Input level Volume
SPEAKER OUT
SUBWOOFER
OUTPUT
FRONT
(DVD)
CENTER SURROUND
SURROUND
BACK
PRESENCE
(SP1)
ZONE2
(SP2)
Both ch, -20 dBm +6.5 dB +13.0 dBm +13.0 dBm +13.0 dBm +13.0 dBm -∞ -∞ -16.0 dBm
A5.MultichIN
8chINPUT6^
A5.MultichIN
6chINPUT8^
A5.MultichIN
8chINPUT8^
A5.MultichIN
6chINPUT6^
