Yamaha RX-V3900 Service Manual

97
RX-V3900/DSP-AX3900
RX-V3900/
DSP-AX3900
IC105: YTD-446CZ (D-VIDEO P.C.B.)
VNP2 (Video and network processor)
* No replacement part available. /
サービス部品供給なし
Memory
Controller0
Memory
Controller1
SD Host I/F 0
SD Host I/F 1
USB
Encryption
Engine
ARM926EJ-S
ARM9EJ-S MMU
Programmable
DSP
Audio I/F
Audio Engine
Network Engine
802.3
MAC0
802.3
MAC1
Memory I/F
SD Host
I-cache
16KB
D-cache
16KB
JTAG
D-TCM
16KB
DMA
I-TCM
16KB
Dual Timer0
Power Manager
I2C
UART2
UART1
UART0
SPI
GPIO
Clock Gen.
PLL
Reset Control
Dual Timer1
Watchdog
Timer
Interrupt
Controller
