15 European Standards
YASKAWA TOEPC71061723A YASKAWA AC Drive CR700 Quick Start Guide 101
Model EMC Noise Filter Model Quantity Manufacturer
4371A FS5972-410-99 1 Schaffner
4414A FS5972-600-99 1 Schaffner
4453A FS5972-600-99 1 Schaffner
4605A FS5972-410-99 2 Schaffner
■ DC Reactor
Install the DC reactor listed in Table 15.13 for drive models 2003, 2005, 4002, 4003 to comply with IEC/EN
61000-3-2.
Table 15.13 DC Reactors for Harmonic Suppression
Drive Model
DC Reactor
Manufacturer: Yaskawa Electric Corporation
Model Rating
2003 UZDA-B 5.4 A, 8 mH
2005 UZDA-B 5.4 A, 8 mH
4002 UZDA-B 3.2 A, 28 mH
4003 UZDA-B 3.2 A, 28 mH
EN
