12 Drive Control, Duty Modes, and Programming
YASKAWA TOEPC71061723A YASKAWA AC Drive CR700 Quick Start Guide 55
No. Name
Application Preset (A1-06 Setting)
Crane (Hoist)
(1)
Crane (Traveling)
(2)
Closed Loop Crane (Hoist)
(3)
C1-02
Deceleration Time 1
3.0 s 3.0 s 3.0 s
C1-09
Fast Stop Time
2.0 s 2.0 s 2.0 s
d1-01
Reference 1
5.00 Hz 5.00 Hz 5.00 Hz
d1-02
Reference 2
25.00 Hz 25.00 Hz 25.00 Hz
d1-03
Reference 3
50.00 Hz 50.00 Hz 50.00 Hz
E1-03
V/f Pattern Selection
F: Custom - F: Custom
F1-05
Encoder 1 Rotation Selection
- - 1: Pulse B leads in FWD Direction
H1-05
Terminal S5 Function Selection
- 3: Multi-Step Speed Reference 1 -
H1-06
Terminal S6 Function Selection
- 4: Multi-Step Speed Reference 2 -
H1-07
Terminal S7 Function Selection
- 6: Jog Reference Selection -
H2-01
Term M1-M2 Function Selection
21: Brake Release Command 0: During Run 21: Brake Release Command
H2-02
Term M3-M4 Function Selection
1: Zero Speed 37: During Frequency Output 1: Zero Speed
H3-06
Terminal A3 Function Selection
F: Not Used F: Not Used F: Not Used
L2-03
Minimum Baseblock Time
0.1 s - 0.1 s
L3-04
Stall Prevention during Decel
0: Disabled 0: Disabled 0: Disabled
L4-01
Speed Agree Detection Level
0.0 Hz - -
L4-02
Speed Agree Detection Width
0.0 Hz - -
L8-05
Input Phase Loss Protection Sel
1: Enabled 1: Enabled 1: Enabled
L8-07
Output Phase Loss Protection Sel
1: Enabled 1: Enabled 1: Enabled
L8-38
Carrier Frequency Reduction
1: Enabled below 6 Hz 1: Enabled below 6 Hz 1: Enabled below 6 Hz
L8-41
High Current Alarm Selection
1: Enabled 1: Enabled 1: Enabled
S1-01
Brake Release Frequency (FWD)
2.0 Hz 0.0 Hz 0.0 Hz
S1-02
Brake Release Frequency (REV)
2.0 Hz 0.0 Hz 0.0 Hz
S1-03
Brake Delay Frequency
3.0 Hz 0.0 Hz 0.0 Hz
S1-04
Brake Delay Time
0.30 s 0.00 s 0.00 s
S1-09
Torque Compensation (FWD)
50% - 0%
S1-12
Brake Hold Frequency (FWD)
3.0 Hz 0.0 Hz 3.0 Hz
S1-13
Brake Hold Frequency (REV)
3.0 Hz 0.0 Hz 3.0 Hz
S1-14
Slip Prevention Frequency
3.0 Hz 0.0 Hz 0.0 Hz
S1-15
Slip Prevention Time
0.30 s 0.00 s 0.00 s
S1-16
Sequence Fault SE1 Detect Time
0.30 s 0.00 s 0.30 s
S1-17
Sequence Fault SE2 Detect Time
1.00 s 0.00 s 1.00 s
S1-18
Sequence Fault SE3 Detect Time
0.50 s 0.00 s 0.50 s
S1-19
Sequence Fault SE4 Detect Time
0.50 s 0.00 s 0.50 s
S1-54
Brake Sequence Selection
1: Enabled 0: Disabled 1: Enabled
Note:
When A1-06 [Application Preset] ≠ 0, the drive shows different parameters on the keypad for different application presets. Set A1-13
[All Function Parameter Display] = 0 to show all available parameters.
◆ Control Method Selection
This section describes the following basic control methods:
• V/f Control
• Open Loop Vector Control
Refer to the Technical Manual for details on speed feedback motor control methods.
