15 European Standards
YASKAWA TOEPC71061723A YASKAWA AC Drive CR700 Quick Start Guide 89
Drive Model
Semiconductor Protection Fuse Rated Current
Manufacturer: EATON/Bussmann
2115
FWH-275A
FWH-300A
*1
2145
FWH-275A
FWH-350A
*1
2180
FWH-325A
FWH-450A
*1
2215 FWH-600A
2283 FWH-800A
2346 FWH-1000B
2415 FWH-1000B
*1 Yaskawa recommends a fuse with a large rated current for applications with repeated loads.
Three-Phase 400 V Class
Table 15.5 Factory-Recommended Branch Circuit Protection (400 V Class)
Drive Model
Semiconductor Protection Fuse Rated Current
Manufacturer: EATON/Bussmann
4002 FWH-50B
4003 FWH-50B
4005 FWH-50B
4006 FWH-60B
4007 FWH-60B
4009 FWH-60B
4015 FWH-80B
4018 FWH-90B
4024 FWH-150B
4031 FWH-200B
4039 FWH-200B
4045 FWH-225A
4060 FWH-250A
4075 FWH-275A
4091 FWH-275A
4112 FWH-300A
4150
FWH-325A
FWH-400A
*1
4180 FWH-500A
4216 FWH-600A
4260 FWH-700A
4304 FWH-800A
4371 FWH-1000B
4414 FWH-1200B
4453 FWH-1200B
4605
FWH-1400A
FWH-1600A
*1
*1 Yaskawa recommends a fuse with a large rated current for applications with repeated loads.
■ CE Standards Compliance for DC Power Supply Input
To comply with CE Standards, install a fuse for the DC power supply input.
Figure 15.3 shows a wiring example for a DC power supply with two drives connected in parallel.
