SECTION 3 - HANDLING, STORAGE, AND INSTALLATION

FIGURE 29 - HEX HEAD SCREW FOR OUTDOOR

ROOF SEAM CAP, PIPE CHASE, AND RAIN HOOD -

1/4 IN-14 X 1 IN (P/N 021-30530-052)

LD116513

FIGURE 30 - BUTYL TAPE - 3/16 IN X 3/4 IN X 40 FT

(P/N 013E-03327-010)

LD116509

FIGURE 31 - POLYURETHANECAULK

(P/N 021-19568-000 - GREY; P/N 013-03317-040 -

CHAMPAGNE) FOR PIPE CHASE ONLY

LD116505

Never use silicone caulk/sealant in or on

any air handling equipment.

FIGURE 32 - ROOF SEAM CAP (ASSEMBLED)

LD17322

FIGURE 33 - PIPE CHASE, TRIM ANGLE, AND

COVER

LD16502

Apply 2 in. Gasket

and Caulk

Apply Caulk

Pipe Chase Base Rail Cover

Pipe Chase

Trim Angle

Apply 2 in.

Gasket

and Caulk
