SECTION 3 - HANDLING, STORAGE, AND INSTALLATION
FORM 102.20-N1
ISSUE DATE: 7/06/2016
3
SINGLE FILTER
CLAMPS
(PERIMETER)
RED
DOUBLE
FILTER
CLAMPS
(T. SECTION)
SILVER
Used with 2 in. pre-lter and SH Single Header
Final Filters. P/N: 026-35788-702
Used with 2-in. (C86) and 4-in. (C89) pre-lter
combined with a Single Header Final Filter.
C86 P/N: 026-35788-604.
C89 P/N: 026-35788-605
Used with 2-in. and 4-in. pre-lter combined
with a double header (DH) nal lter.
P/N: 026-35788-612
Used with 2-in. Pre-lter Combined with
a DH Final Filter. P/N: 026-35788-625
Used with 4 in. Pre-lter Combined with
a DH Final Filter. P/N: 026-35788-626
Used to Attach HEPA Filters to Holding Frame.
HEPA Arm Filter ClipHEPA Arm Filter Clip
Used to Attach HEPA Filters to KOCH Holding
Frame. Leg P/N: 029-22081-001.
Latch P/N: 029-22081-002.
Used with 2-in. Pre-lter Combined with
a 4-in. Final Filter. P/N: 026-35788-609
FIGURE 147 - FILTER LATCHES
LD13303c
