SECTION 3 - HANDLING, STORAGE, AND INSTALLATION

FORM 102.20-N1

ISSUE DATE: 7/06/2016

TABLE 6 - AAF CLIPS FOR FILTER FRAMES - SINGLE FILTER APPLICATION

2 IN PERFECTPLEAT,

PREMIUM OR

PREMIUM HM

4 IN AMAIR 300X

VARICEL SINGLE

HEADER (SH) OR

DRIPAK 2000

VARICEL DOUBLE

HEADER (DH)

FILTER FRAME

12X24 - 16 G

GALVANIZED

P/N 026-35778-000 X X

P/N 026-35778-007 X

P/N 026-35778-006 X

FILTER FRAME

24X24 - 16 G

GALVANIZED

P/N 026-35778-000 X X

P/N 026-35778-007 X

P/N 026-35778-006 X

TABLE 7 - AAF PRE-FILTER/FINAL FILTER APPLICATION

PERFECTPLEAT,

PREMIUM OR HM

AND VARICEL SH OR

DRIPAK 2000

PERFECTPLEAT,

PREMIUM OR HM

AND VARICEL DH

4 IN AMAIR 300X

AND VARICEL SH OR

DRIPAK 2000

4 IN AMAIR 300X

AND VARICEL DH

FILTER FRAME

12X24 - 16 G

GALVANIZED

P/N 026-35778-007

and 026-35778-000

P/N 026-35778-006

and 026-36339-001

P/N 026-35778-007,

026-35778-008 and

026-35778-000

P/N 026-35778-006

and 026-36339-000

FILTER FRAME

24X24 - 16 G

GALVANIZED

P/N 026-35778-007

and 026-35778-000

P/N 026-35778-006

and 026-36339-001

P/N 026-35778-007,

026-35778-008 and

026-35778-000

P/N 026-35778-006

and 026-36339-000

Note: When lters are supplied by other companies, the lter clips are supplied as well.
