SECTION 2 - RIGGING AND LIFTING
FORM 160.84-N1
ISSUE DATE: 11/22/2016
2
FORM 2 TOTAL WEIGHT
The heaviest possible YMC² combination of total
weight for Form 2 shipment is 21,900 lbs (10,000 kg)
or 11 ton. See Weights on page 73 for YMC² weight
breakdown.
The actual unit total shipping and operat-
ing weight is on the submittal drawings.
FORM 2 SHIPMENT
Arrangements with the local service of-
ce must be made to ensure refrigerant is
on-site when unit is ready to be charged.
The chiller is shipped complete with miscellaneous
items shipped together.
• The driveline (compressor/motor assembly) is
mounted and all the necessary interconnecting
piping is assembled.
• The complete unit is factory leak-tested, evacu-
ated and shipped charged with a 3 to 7 PSIG (20
to 50 kPa) holding charge of dry nitrogen.
• The OptiView™ Control Center is mounted.
• The Power Panel is mounted on the unit.
• The Variable Speed Drive (VSD) is mounted,
wired and shipped with Glycol.
• Refrigerant charges are shipped separately.
Unit Rigging
One lifting chain is required for each lift-
ing point and each chain having a work-
ing load limit 30% of unit total weight.
The lifting chains traversing the evapora-
tor/condenser shells should remain 90°
+/- 10° from horizontal. A spreader bar
may be required to achieve the +/- 10°.
1. Attach rigging chains to an adequate lifting device.
2. Attach chains to the lifting holes at the corner of
each end sheet as shown on Figure 2 on page 16.
3. If necessary to avoid contact with chiller compo-
nents install side spreader bars between the Evap-
orator and Condenser end sheet lifting chains.
4. The angle of the lifting chains traversing the en
sheet should not be less than 65° as shown on Fig-
ure 2 on page 16.
5. With an adequate lifting device lift the unit slight-
ly off the ground to determine adjustments neces-
sary to keep the unit level. Make adjustments as
necessary to level the unit.
