York YMC2 Installation And Assembly

JOHNSON CONTROLS
73
SECTION 5 - DIMENSIONS, NOZZLE ARRANGEMENTS AND WEIGHTS
FORM 160.84-N1
ISSUE DATE: 11/22/2016
5
WEIGHTS (CONT'D)
TABLE 25 - APPROXIMATE VARIABLE SPEED DRIVE (VSD) WEIGHTS
VSD WEIGHT LBS (KG)
HYP0490XH 1226 (556)
HYP0612XH 1954 (886)
HYP0774XH 2060 (934)
HYP1278XH 3806 (1727)
TABLE 26 - APPROXIMATE DRIVELINE WEIGHTS
COMPRESSOR WEIGHT LBS (KG)
M2C-197FAC 2872 (1303)
M2C-197FACD 2,861 (1292)
M2C-205FAC 2879 (1306)
M2C-205FACD 2,867 (1295)
M2C-218FAC 2998 (1360)
M2C-233FAC 3011 (1366)
M2C-246FAC 3009 (1365)
M6C-295FAC 4298 (1950)
M6C-331FAC 4500 (2041)
TABLE 27 - APPROXIMATE REFRIGERANT & WATER WEIGHT
EVAPORATOR CONDENSER
REFRIGERANT WEIGHT
LBS (KG)*
WATER WEIGHT
LBS (KG)**
EB2508 CC2508 487 (220) 748 (340)
EB2510
CB2110 540 (250) 980 (450)
CB2510 600 (270) 1310 (600)
EB2514 CB2514 840 (380) 1680 (770)
EB2910
CB2510 640 (290) 1510 (690)
CB2910 860 (390) 1760 (800)
EB2914
CB2514 900 (410) 1940 (880)
CB2914 1210 (550) 2240 (1020)
EB3310
CB2910 920 (420) 2070 (940)
CB3310 980 (450) 2580 (1170)
EB3314
CB2914 1290 (590) 2640 (1200)
CB3314 1380 (630) 3310 (1510)
EC3312 CB2912 1331 (605) 2863 (1299)
EC3314 CB3314 1626 (739) 3589 (1628)
EC3914
CB3314 1908 (867) 4232 (1920)
CB3914 2072 (942) 4892 (2220)
*Refrigerant Weight based on maximum tube bundle.
** Water Weight is the total water in both shells and for 150PSI, 2-pass, compact water boxes.
Refer to product submittal drawings for
detailed weight information specic to the
unit ordered.
