SECTION 5 - DIMENSIONS, NOZZLE ARRANGEMENTS AND WEIGHTS
M6 MOTOR
TABLE 15 - EVAPORATOR WEIGHTS, DRY*
M6 MOTOR CHILLERS
EVAPORATOR
150PSI COMPACT
WATER BOX WEIGHT
LBS (KG)
300PSI COMPACT
WATER BOX WEIGHT
LBS (KG)
150PSI MARINE WA-
TER BOX WEIGHT
LBS (KG)
300PSI MARINE WA-
TER BOX WEIGHT
LBS (KG)
CODE
WEIGHT
LBS
(KG)
1-PASS 2-PASS 3-PASS 1-PASS 2-PASS 3-PASS 1-PASS 2-PASS 3-PASS 1-PASS 2-PASS 3-PASS
EC3312
7477
(3392)
340
(154)
383
(174)
380
(172)
1062
(482)
943
(428)
878
(398)
1822
(826)
1101
(499)
1850
(839)
3214
(1458)
1998
(906)
2986
(1354)
EC3314
8389
(3805)
340
(154)
383
(174)
380
(172)
1062
(482)
943
(428)
878
(398)
1822
(826)
1101
(499)
1850
(839)
3214
(1458)
1998
(906)
2986
(1354)
EC3914
11834
(5368)
678
(308)
712
(323)
740
(336)
1430
(649)
1310
(594)
1266
(574)
2778
(1260)
1785
(810)
2856
(1295)
4740
(2150)
2947
(1337)
4502
(2042)
*Weights based on maximum tube bundle allowed per shell.
Shell weights assume max bundle size (for 3/4" tube), heaviest tube (e-179; c-203), 300#water (if available)
Waterbox weight includes both waterboxes and covers/return
TABLE 16 - CONDENSER WEIGHTS, DRY*
M6 MOTOR CHILLERS
CONDENSER
150PSI COMPACT
WATER BOX WEIGHT
LBS (KG)
300PSI COMPACT
WATER BOX WEIGHT
LBS (KG)
150PSI MARINE WA-
TER BOX WEIGHT
LBS (KG)
300PSI MARINE WA-
TER BOX WEIGHT
LBS (KG)
CODE
WEIGHT
LBS
(KG)
1-PASS 2-PASS 3-PASS 1-PASS 2-PASS 3-PASS 1-PASS 2-PASS 3-PASS 1-PASS 2-PASS 3-PASS
CB2912
7473
(3390)
340
(154)
354
(161)
354
(161)
852
(386)
735
(333)
678
(308)
1408
(639)
891
(404)
1416
(642)
2360
(1070)
1468
(666)
2170
(984)
CB3314
9782
(4437)
406
(184)
419
(190)
444
(201)
1066
(484)
845
(383)
872
(396)
1918
(870)
1159
(526)
1888
(856)
3098
(1405)
1827
(829)
2816
(1277)
CB3914
10297
(4671)
692
(314)
757
(343)
740
(336)
1630
(739)
1436
(651)
1272
(577)
2944
(1335)
1849
(839)
2964
(1344)
4924
(2234)
2998
(1360)
4410
(2000)
*Weights based on maximum tube bundle allowed per shell.
Shell weights assume max bundle size (for 3/4" tube), heaviest tube (e-179; c-203), 300#water (if available)
Waterbox weight includes both waterboxes and covers/return
