JOHNSON CONTROLS
70
FORM 160.84-N1
ISSUE DATE: 11/22/2016
SECTION 5 - DIMENSIONS, NOZZLE ARRANGEMENTS AND WEIGHTS
TABLE 17 - APPROXIMATE EVAPORATOR WEIGHTS 150 PSI COMPACT WATER BOXES
EVAPORATOR COMPACT WATER BOX WEIGHT LBS (KG) MARINE WATER BOX WEIGHT LBS (KG)
CODE
WEIGHT LBS
(KG)
1-PASS 2-PASS 3-PASS 1-PASS 2-PASS 3-PASS
EB2508 2830 (1284) 264 (120) 269 (122) 272 (123) 474 (215) 563 (255) 514 (233)
EB2510 3628 (1646) 264 (120) 269 (122) 272 (123) 474 (215) 563 (255) 514 (233)
EB2514 4545 (2062) 264 (120) 269 (122) 272 (123) 474 (215) 563 (255) 514 (233)
EB2910 4338 (1968) 332 (151) 355 (161) 360 (163) 624 (283) 731 (332) 688 (312)
EB2914 5502 (2496) 332 (151) 355 (161) 360 (163) 624 (283) 731 (332) 688 (312)
EB3310 5372 (2437) 402 (182) 421 (191) 432 (196) 776 (352) 851 (386) 826 (375)
EB3314 6779 (3075) 402 (182) 421 (191) 432 (196) 776 (352) 851 (386) 826 (375)
NOTE: Weights based on maximum tube bundle allowed per shell.
TABLE 18 - APPROXIMATE CONDENSER WEIGHTS 150 PSI COMPACT WATER BOXES
CONDENSER COMPACT WATER BOX WEIGHT LBS (KG) MARINE WATER BOX WEIGHT LBS (KG)
CODE
WEIGHT
LBS (KG)
1-PASS 2-PASS 3-PASS 1-PASS 2-PASS 3-PASS
CC2508 2918 (1324) 282 (128) 281 (127) 284 (129) 588 (267) 606 (275) 574 (260)
CB2110 2635 (1195) 230 (104) 219 (99) 230 (104) 464 (210) 457 (207) 444 (201)
CB2510 3309 (1501) 282 (128) 281 (127) 284 (129) 588 (267) 606 (275) 574 (260)
CB2514 4532 (2056) 282 (128) 281 (127) 284 (129) 588 (267) 606 (275) 574 (260)
CB2910 4258 (1931) 340 (154) 354 (161) 354 (161) 688 (312) 752 (341) 710 (322)
CB2914 5854 (2655) 340 (154) 354 (161) 354 (161) 688 (312) 752 (341) 710 (322)
CB3310 5343 (2424) 406 (184) 419 (190) 444 (201) 816 (370) 851 (386) 814 (369)
CB3314 7362 (3339) 406 (184) 419 (190) 444 (201) 816 (370) 851 (386) 814 (369)
NOTE: Weights based on maximum tube bundle allowed per shell.
WEIGHTS
