320 Additional parameter data
40.38 Set 1 output freeze enable Binary src --1 = 1
40.39 Set 1 deadband range Real 0……200000.0 - 10 = 1
40.40 Set 1 deadband delay Real 0.0 … 3600.0 s 10 = 1 s
40.43 Set 1 sleep level Real 0……200000.0 - 10 = 1
40.44 Set 1 sleep delay Real 0.0…3600.0 s 10 = 1 s
40.45 Set 1 sleep boost time Real 0.0…3600.0 s 10 = 1 s
40.46 Set 1 sleep boost step Real -0……200000.0 PID
customer
units
100 = 1 PID
customer unit
40.47 Set 1 wake-up deviation Real -200000.00…200000.00 PID
customer
units
100 = 1 PID
customer unit
40.48 Set 1 wake-up delay Real 0.00…60.00 s 100 = 1 s
40.49 Set 1 tracking mode Binary src --1 = 1
40.50 Set 1 tracking ref selection Analog src --1 = 1
40.51 Set 1 trim mode List 0…3 - 1 = 1
40.52 Set 1 trim selection List 1…3 - 1 = 1
40.53 Set 1 trimmed ref pointer Binary src --1 = 1
40.54 Set 1 trim mix Real 0.000 … 1.000 - 1000 = 1
40.55 Set 1 trim adjust Real -100.000 … 100.000 - 1000 = 1
40.56 Set 1 trim source List 1…2 - 1 = 1
40.57 PID set1/set2 selection Binary src --1 = 1
40.58 Set 1 increase prevention List 0…3 - 1 = 1
40.59 Set 1 decrease prevention List 0…3 - 1 = 1
40.60 Set 1 PID activation source Binary src --1 = 1
40.61 Setpoint scaling actual Real -200000.00…200000.00 - 100 = 1
40.62 PID internal setpoint actual Real -200000.00…200000.00 PID
customer
units
100 = 1 PID
customer unit
40.65 Trim auto connection List 0…1 - 1 = 1
40.79 Set 1 units List --1=1
40.80 Set 1 PID output min source Analog src --1=1
40.81 Set 1 PID output max source Analog src --1=1
40.89 Set 1 setpoint multiplier Real -200000.00…200000.00 - 100 = 1
40.90 Set 1 feedback multiplier Real --200000.00…200000.00 - 100 = 1
40.91 Feedback data storage Real
-327.68 … 327.67 - 100 = 1
40.92 Setpoint data storage Real -327.68 … 327.67 - 100 = 1
40.96 Process PID output % Real -100.00…100.00 % 100 = 1
40.97 Process PID feedback % Real -100.00…100.00 % 100 = 1
40.98 Process PID setpoint % Real -100.00…100.00 % 100 = 1
40.99 Process PID deviation % Real -100.00…100.00 % 100 = 1
41 Process PID set 2
41.08 Set 2 feedback 1 source Analog src --1 = 1
No. Name Type Range Unit FbEq32
ACS180 FW.book Page 320 Tuesday, March 9, 2021 2:25 PM

ABB ACS180 Specifications

General

Product Type	DC Drive
Number of Phases	1 or 3
IP Rating	IP20
Communication Interfaces	Modbus RTU
Protection Features	Overcurrent, Overvoltage, Undervoltage, Overtemperature, Short Circuit
Operating Temperature	-10°C to +50°C
Storage Temperature	-40 to +70 °C
Relative Humidity	5 to 95 % non-condensing
Altitude	Up to 1000 m
