Additional parameter data 321
41.09 Set 2 feedback 2 source Analog src --1 = 1
41.10 Set 2 feedback function List 0…11 - 1 = 1
41.11 Set 2 feedback filter time Real 0.000…30.000 s 1000 = 1 s
41.14 Set 2 setpoint scaling Real -200000.00…200000.00 - 100 = 1
41.15 Set 2 output scaling Real -200000.00…200000.00 - 100 = 1
41.16 Set 2 setpoint 1 source Analog src --1 = 1
41.17 Set 2 setpoint 2 source Analog src --1 = 1
41.18 Set 2 setpoint function List 0…11 - 1 = 1
41.19 Set 2 internal setpoint sel1 Binary src --1 = 1
41.20 Set 2 internal setpoint sel2 Binary src --1 = 1
41.21 Set 2 internal setpoint 1 Real -200000.00…200000.00 PID
customer
units
100 = 1 PID
customer unit
41.22 Set 2 internal setpoint 2 Real -200000.00…200000.00 PID
customer
units
100 = 1 PID
customer unit
41.23 Set 2 internal setpoint 3 Real -200000.00…200000.00 PID
customer
units
100 = 1 PID
customer unit
41.24 Set 2 internal setpoint 0 Real -200000.00…200000.00 PID
customer
units
100 = 1 PID
customer unit
41.26 Set 2 setpoint min Real -200000.00…200000.00 - 100 = 1
41.27 Set 2 setpoint max Real -200000.00…200000.00 - 100 = 1
41.28 Set 2 setpoint increase time Real 0.0…1800.0 s 10 = 1 s
41.29 Set 2 setpoint decrease time Real 0.0…1800.0 s 10 = 1 s
41.30 Set 2 setpoint freeze enable Binary src --1 = 1
41.31 Set 2 deviation inversion Binary src --1 = 1
41.32 Set 2 gain Real 0.01…100.00 - 100 = 1
41.33 Set 2 integration time Real 0.0…9999.0 s 10 = 1 s
41.34 Set 2 derivation time Real 0.000…10.000 s 1000 = 1 s
41.35 Set 2 derivation filter time Real 0.0…10.0 s 10 = 1 s
41.36 Set 2 output min Real -200000.00… 200000.00 - 10 = 1
41.37 Set 2 output max Real -200000.00… 200000.00 - 10 = 1
41.38 Set 2 output freeze enable Binary src --1 = 1
41.39 Set 2 deadband range Real 0……200000.0 - 10 = 1
41.40 Set 2 deadband delay
Real 0.0 … 3600.0 s 10 = 1 s
41.43 Set 2 sleep level Real 0.0…20000.00 - 10 = 1
41.44 Set 2 sleep delay Real 0.0…3600.0 s 10 = 1 s
41.45 Set 2 sleep boost time Real 0.0…3600.0 s 10 = 1 s
41.46 Set 2 sleep boost step Real 0.0…20000.00 PID
customer
units
100 = 1 PID
customer unit
No. Name Type Range Unit FbEq32
