108 Practical examples
Setting the parameters according to grid code
Parameter setting examples in cases of Spanish, Italian and United Kingdom grid codes
are given below.
 Spanish grid code
Parameter Setting
Control program AJXC2330 (or newer) parameters:
30.05 AC OVERVOLT TRIP 793.5 V
30.06 AC UNDERVOLT TRIP 68.9999 V
30.07 AC OVERFREQ TRIP 53 Hz
30.08 AC UNDERFREQ TRIP 47 Hz
31.01 CROWBAR HW TYPE ACTIVE CB
32.01 GRID SUPPORT MODE MAX. Up-p
32.02 RT MONITOR SIGNAL MIN. Up-p
32.03 RT U/Un LEVEL1 80%
32.04 RT U/Un LEVEL2 9.99999%
32.05 RT U/Un LEVEL 3 70%
32.06 RT U/Un DELTA t1 3000 ms
32.07 RT U/Un DELTA t2 600 ms
32.08 RT U/Un DELTA t3 12000 ms
32.09 RT U/Un DELTA t4 3000 ms
32.10 RT U/Un LEVELHYST 5%
32.11 GS U/Un LEVEL 1 85%
32.12 GS U/Un LEVEL 2 50%
32.13 GS U/Un LEVEL 3 25%
32.14 GS U/Un LEVEL 4 15%
32.15 GS U/Un LEVEL 5 110%
32.16 GS U/Un LEVEL 6 120%
32.17 GS IQREF LEVEL 1 9.99999%
32.18 GS IQREF LEVEL 2 100%
32.19 GS IQREF LEVEL 3 100%
32.20 GS IQREF LEVEL 4 100%
32.21 GS IQREF LEVEL 5 -20%
32.24 GS TIME AFTER DIP 500 ms
32.25 KVAR RISE TIME 120 ms
32.26 TORQUE RISE TIME 99.9999 ms
32.27 TMAX/TN (LVRT) 4.99997%
32.28 TMIN/TN (LVRT) 3.00002%
32.29 RT MAX POWER 100%
32.30 IR MAX PEAK LEVEL 2285.57 A
32.31 IR MAXSLOPE SCALE 507.903 A
32.32 U- / U+ START DIS 45%
32.33 U(RMS) START DIS 9.99999%
32.41 ENVELOPE PAR SEL PAR 1
