Start-up with low voltage stator 51
It is useful to record important signals with the DriveWindow monitoring PC tool.
01.01 MOTOR SPEED [rpm]
01.10 DC VOLTAGE [V]
01.11 MAINS VOLTAGE [V]
02.01 STATOR IS [RMS]
02.02 STATOR VOLTAGE [V]
02.06 ROTOR IR [RMS]
The figure below shows a typical start in local mode.
Stop the rotor-side converter with the DriveWindow STOP button.
Stator voltage synchronization test
Monitor the following rotor-side converter signals with DriveWindow
datalogger with 0.3 ms time level. Trigger condition must be 06.07
STATOR U FLUX and trig level 40 with rising edge.
06.03 ROTOR IU
06.04 ROTOR IY
06.07 STATOR U FLUX
06.05 GRID U FLUX
06.08 STATOR Y FLUX
06.06 GRID Y FLUX
06.03 ROTOR IU
06.04 ROTOR IY
06.07 STATOR U FLUX
06.05 GRID U FLUX
06.08 STATOR Y FLUX
06.06 GRID Y FLUX
Start the DriveWindow datalogger.
Start the rotor-side converter with the DriveWindow START button.
[??
?
??
??
??
??
K???
K??
K??
?K}>|K?
"=KK'K?JX#_`\jX{ "=K'KK!`"Z%X#_`\jX{ "=}'?%`#X#_`\jX{
"='?##"$!%&j`{ "=>'?K%`#"%$!%&j`{ "=K'?K!##%+\\Jj={
