Practical examples 109
 Italian grid code
Parameter Setting
Control program AJXC2330 (or newer) parameters:
4.04 DEVICE ID INU 800 1160_7NC
20.23 USER KVAR LIMIT 100%
30.05 AC OVERVOLT TRIP 828
30.06 AC UNDERVOLT TRIP (2) (V) 69
30.07 AC OVERFREQ TRIP 53 Hz
30.08 AC UNDERFREQ TRIP 47 Hz
30.15 DLYED AC OV TRIP (V) 759
30.16 AC OV TRIP DLY (s) 1.5
31.01 CROWBAR HW TYPE ACTIVE CB
32.01 GRID SUPPORT MODE MAX. Up-p
32.02 RT MONITOR SIGNAL MIN. Up-p
32.03 RT U/Un LEVEL1 (1) 85%
32.04 RT U/Un LEVEL2 (4) 10%
32.05 RT U/Un LEVEL 3 (5) 75%
32.06 RT U/Un DELTA t1 (6) (ms) 800
32.07 RT U/Un DELTA t2 (3) (ms) 500
32.08 RT U/Un DELTA t3 (8) (ms) 2000
32.09 RT U/Un DELTA t4 (ms) 0 ms
32.10 RT U/Un LEVELHYST (7) 10%
32.11 GS U/Un LEVEL 1 90%
32.12 GS U/Un LEVEL 2 80%
32.13 GS U/Un LEVEL 3 25%
32.14 GS U/Un LEVEL 4 15%
32.15 GS U/Un LEVEL 5 110%
32.16 GS U/Un LEVEL 6 120%
32.17 GS IQREF LEVEL 1 0%
32.18 GS IQREF LEVEL 2 112%
32.19 GS IQREF LEVEL 3 112%
32.20 GS IQREF LEVEL 4 112%
32.21 GS IQREF LEVEL 5 -20%
32.22 GS IQREF LEVEL 6 -40%
32.23 GS AFTER DIP 0%
32.24 GS TIME AFTER DIP 0 ms
32.25 KVAR RISE TIME 50 ms
32.26 TORQUE RISE TIME 50 ms
32.27 Imax/In (LVRT) 124%
32.28 TMIN/TN (LVRT) 1%
32.29 Ip max/In (LVRT) 118%
32.30 IR MAX PEAK LEVEL 1777.66 A
32.31 IR MAXSLOPE SCALE 507.903 A
32.32 U- / U+ START DIS 80%
32.33 U(RMS) START DIS 10%
32.34 RT U/Un DELTA t5 (10) (s) 3
