Practical examples 111
UK grid code
Parameter Setting
Control program AJXC2330 (or newer) parameters:
30.03 EARTH FAULT LEVEL 3
30.04 STATOR CURR TRIP 0 A
30.05 AC OVERVOLT TRIP 793.5 V
30.06 AC UNDERVOLT TRIP 0 V
30.07 AC OVERFREQ TRIP 53 Hz
30.08 AC UNDERFREQ TRIP 47 Hz
32.01 GRID SUPPORT MODE MAX. Up-p
32.02 RT MONITOR SIGNAL MIN. Up-p
32.03 RT U/Un LEVEL1 90%
32.04 RT U/Un LEVEL2 15%
32.05 RT U/Un LEVEL 3 80%
32.06 RT U/Un DELTA t1 1200 ms
32.07 RT U/Un DELTA t2 140 ms
32.08 RT U/Un DELTA t3 2500 ms
32.09 RT U/Un DELTA t4 140 ms
32.10 RT U/Un LEVELHYST 5%
32.11 GS U/Un LEVEL 1 90%
32.12 GS U/Un LEVEL 2 80%
32.13 GS U/Un LEVEL 3 25%
32.14 GS U/Un LEVEL 4 15%
32.15 GS U/Un LEVEL 5 110%
32.16 GS U/Un LEVEL 6 120%
32.17 GS IQREF LEVEL 1 0%
32.18 GS IQREF LEVEL 2 112%
32.19 GS IQREF LEVEL 3 112%
32.20 GS IQREF LEVEL 4 112%
32.21 GS IQREF LEVEL 5 -20%
32.22 GS IQREF LEVEL 6 -40%
32.23 GS AFTER DIP 0%
32.24 GS TIME AFTER DIP 0 ms
32.25 KVAR RISE TIME 50 ms
32.26 TORQUE RISE TIME 49.9988 ms
32.27 Imax/In (LVRT) 124%
32.28 TMIN/TN (LVRT) 0.999975%
32.29 Ip max/In (LVRT) 118%
32.30 IR MAX PEAK LEVEL 1777.68 A
32.31 IR MAXSLOPE SCALE 507.903 A
32.32 U- / U+ START DIS 80%
32.33 U(RMS) START DIS 9.99999%
32.34 RT U/Un DELTA t5 180 s
32.35 PRIORITY t<t4 Iq > Ip
32.36 PRIORITY t>t4 Ip > Iq
32.37 P/Q UNSYM DIS 62%
