ABB ACS880 PCP User Manual

104 Parameters
46 Monitoring/scaling settings Speed supervision settings; actual signal filtering; general
scaling settings.
280
47 Data storage Data storage parameters that can be written to and read from
using other parameters’ source and target settings.
281
49 Panel port communication Communication settings for the control panel port on the drive. 283
50 Fieldbus adapter (FBA) Fieldbus communication configuration. 284
51 FBA A settings Fieldbus adapter A configuration. 291
52 FBA A data in Selection of data to be transferred from drive to fieldbus
controller through fieldbus adapter A.
293
53 FBA A data out Selection of data to be transferred from fieldbus controller to
drive through fieldbus adapter A.
293
54 FBA B settings Fieldbus adapter B configuration. 294
55 FBA B data in Selection of data to be transferred from drive to fieldbus
controller through fieldbus adapter B.
295
56 FBA B data out Selection of data to be transferred from fieldbus controller to
drive through fieldbus adapter B.
296
58 Embedded fieldbus Configuration of the embedded fieldbus (EFB) interface. 296
74 Pump setup Basic functions of applications. 303
75 Pump level control Pump level control function. 307
76 Pump pressure protection Pump pressure protection function. 310
77 Pump torque protection Pump torque protection function. 311
78 Pump underload protection Pump underload protection function. 314
79 Pump temperature protection Pump temperature protection function. 315
80 Pump backspin control Basic functions of applications. 316
90 Feedback selection Motor and load feedback configuration. 318
91 Encoder module settings Configuration of encoder interface modules. 327
92 Encoder 1 configuration Settings for encoder 1. 330
93 Encoder 2 configuration Settings for encoder 2. 336
95 HW configuration Various hardware-related settings. 338
96 System Language selection; access levels; macro selection; parameter
save and restore; control unit reboot; user parameter sets; unit
selection.
342
97 Motor control Motor model settings. 348
98 User motor parameters Motor values supplied by the user that are used in the motor
model.
351
99 Motor data Motor configuration settings. 353
200 Safety FSO-xx settings. 359
Group Contents Page

ABB ACS880 PCP Specifications

General

Output current	Up to 5200 A
Input voltage	380-690 V
Power range	5600 kW
Cooling method	Air or liquid
Protection class	IP21, IP54
Communication interfaces	Ethernet, CANopen
