296 Parameters
Act1 32bit Actual value ACT1 (32 bits) 15
Act2 32bit Actual value ACT2 (32 bits) 16
SW2 16bit Status Word 2 (16 bits) 24
Other Source selection (see Terms and abbreviations on
page 101).
-
…… … …
55.12 FBA B data in12 See parameter 55.01 FBA B data in1. None
56
56 FBA B data out
Selection of data to be transferred from fieldbus controller
to drive through fieldbus adapter B.
56.01 FBA B data out1 Parameters 56.01…56.12 select data to be transferred
from the fieldbus controller to the drive through fieldbus
adapter B.
None
None None. 0
CW 16bit Control Word (16 bits) 1
Ref1 16bit Reference REF1 (16 bits) 2
Ref2 16bit Reference REF2 (16 bits) 3
CW 32bit Control Word (32 bits) 11
Ref1 32bit Reference REF1 (32 bits) 12
Ref2 32bit Reference REF2 (32 bits) 13
CW2 16bit Control Word 2 (16 bits) 21
Other Source selection (see Terms and abbreviations on
page 101).
-
…… … …
56.12 FBA B data out12 See parameter 56.01 FBA B data out1. None
58
58 Embedded fieldbus
Configuration of the embedded fieldbus (EFB) interface.
See also chapter Fieldbus control through the embedded
fieldbus interface (EFB) (page 437).
58.01 Protocol enable Enables/disables the embedded fieldbus interface and
selects the protocol to use.
Note: When the embedded fieldbus interface is enabled,
the drive-to-drive link functionality is automatically disabled
None
None None. 0
Modbus RTU Embedded fieldbus interface is enabled and uses the
Modbus RTU protocol.
1
58.02 Protocol ID Displays the protocol ID and revision.
This parameter is read-only.
-
Protocol ID and revision. 1 = 1
58.03 Node address Defines the node address of the drive on the fieldbus link.
Values 1…247 are allowable. Two devices with the same
address are not allowed on-line.
Changes to this parameter take effect after the control unit
is rebooted or the new settings validated by parameter
58.06 Communication control.
1
0…255 Node address (values 1…247 are allowable). 1 = 1
No. Name/Value Description Def/
FbEq16
