ABB ACS880 PCP User Manual

128 Parameters
10
10 Standard DI, RO
Configuration of digital inputs and relay outputs.
10.01 DI status Displays the electrical status of digital inputs DIIL and
DI6…DI1. The activation/deactivation delays of the inputs
(if any are specified) are ignored. A filtering time can be
defined by parameter 10.51 DI filter time.
Bits 0…5 reflect the status of DI1…DI6; bit 15 reflects the
status of the DIIL input. Example: 1000000000010011b =
DIIL, DI5, DI2 and DI1 are on, DI3, DI4 and DI6 are off.
This parameter is read-only.
-
0000h…FFFFh Status of digital inputs. 1 = 1
10.02 DI delayed status Displays the status of digital inputs DIIL and DI6…DI1.
This word is updated only after activation/deactivation
delays (if any are specified).
Bits 0…5 reflect the delayed status of DI1…DI6; bit 15
reflects the delayed status of the DIIL input.
This parameter is read-only.
-
0000h…FFFFh Delayed status of digital inputs. 1 = 1
10.03 DI force selection The electrical statuses of the digital inputs can be
overridden for eg. testing purposes. A bit in parameter
10.04 DI force data is provided for each digital input, and
its value is applied whenever the corresponding bit in this
parameter is 1.
0000h
0000h…FFFFh Override selection for digital inputs. 1 = 1
10.04 DI force data Contains the values that the digital inputs are forced to
when selected by 10.03 DI force selection.
Bit 0 is the forced value for DI1; bit 15 is the forced value
for the DIIL input.
0000h
0000h…FFFFh Forced values of digital inputs. 1 = 1
No. Name/Value Description Def/
FbEq16
Bit Value
0 1 = Force DI1 to value of bit 0 of parameter 10.04 DI force data.
1 1 = Force DI2 to value of bit 1 of parameter 10.04 DI force data.
2 1 = Force DI3 to value of bit 2 of parameter 10.04 DI force data.
3 1 = Force DI4 to value of bit 3 of parameter 10.04 DI force data.
4 1 = Force DI5 to value of bit 4 of parameter 10.04 DI force data.
5 1 = Force DI6 to value of bit 5 of parameter 10.04 DI force data.
6…14 Reserved
15 1 = Force DIIL to value of bit 15 of parameter 10.04 DI force data.
