Parameters 127
0000h...FFFFh Backspin status word 1 = 1
09.14 Pump status word Pump control program status word. 0000h
0000h…FFFFh Pump status word. 1 = 1
09.15 Sleep feedback value Integrated value of sleep signal feedback from different
sources 75.14 Sleep signal source 1 and 75.15 Sleep
signal source 2.
0.00
SourceUnit
-
100000.00...100000.
00
Value range 1 = 1
09.16 Sleep time Period of time when pump is in sleep mode. 0.000 s
0...100000.000 s Value range 10 = 1 s
No. Name/Value Description Def/
FbEq16
Bit Name Description
0 Backspin enabled Backspin function is enabled.
1 Backspin operation active Backspin function is active.
2 Backspin limit active Backspin limit is reached.
3...9 Reserved
10 Start delay enabled Start delay function is enabled.
11 Start delay timer active Start delay function is active.
12...15 Reserved
Bit Name Description
0 Thermal protection alarm level
reached
Alarm due to thermal protection failure.
1 Thermal protection fault level
reached
Drive tripped due to thermal protection failure.
2 Thermal protection active Actual temperature for thermal protection.
3 High pressure presented - digital
sensor
High pressure measured by digital sensor.
4 High pressure presented - analogue
sensor
High pressure measured by analog sensor.
5 High pressure protection active Actual value for high pressure protection.
6 Underload protection active Actual value for underload protection.
7 Rod torque 1 active Actual rod torque 1.
8 Rod torque 2 active Actual rod torque 2.
9 Torque protection active Actual value for torque protection.
10 Sleep mode active Actual value for sleep mode.
11 Fault delay active Fault delay is active.
12 Replace battery Battery from ZCU is needed to replace.
13 Brake confirm active Brake confirm is active.
14 Starting speed active Drive is ready for startup ramp.
15 Rod torque 2 speed Reserved for rod torque 2 speed.
